Product Description
RainBird 100DV - 1 in. DV Series Inline Plastic Residential Irrigation Valve - NPT Threads
1 in. (26/34) standard in-line configuration
Double-filtered pilot-flow design for maximum reliability
Balanced-pressure diaphragm for long life
External bleed to manually flush system of dirt and debris during installation and system start-up
Internal bleed for spray-free manual operation
Energy-efficient, low-power encapsulated solenoid with captured plunger and 90-mesh (200 micron) solenoid filter
Rain Bird manufactures only the highest quality valves. Use DV/DVF series valves in locations where the use of a separate pressure vacuum breaker (PVB) or a double-check valve is required by city codes to protect against back flow. Check your local city codes to determine what type of valves are required.
Additional features:
All of our valves work with any standard sprinkler timer.
Buna-N diaphragm with self-cleaning 90 mesh (200 micron) pilot water filter and captive spring.
Operates in low-flow and Xerigation® applications when the RBY filter is installed upstream.
1.25 in. (3,2 cm) stainless steel phillips head screws.
Accepts latching solenoid for use with Rain Bird battery-operated controllers.
