Product Description
Sugatsune HES2S-150-A110 3-WAY ADJUSTABLE CONCEALED HINGE Frame-Surface Mount
DESCRIPTION
- Surface mount to the door frame for easy installation.
- Recommended door thickness is 1-3/8” (35 mm) or more.
- Opens to 110°. Door stopper is required to prevent breakage of the hinges and failure of the door.
- Compact and sturdy design combined with an exceptionally simple install.
- Durability: successfully passed 300,000 open/close private cycles.
- Adjustable depth ±1/8" (3 mm), vertical ±1/8" (3 mm), horizontal with spacer ±1/16" (1 mm)
