Product Description
STA-RITE FH50 Series 1/2 hp Shallow Well Jet Pump
The FH Series Jet Pump provides best-in-class performance for shallow wells up to 25’ deep and flows over 20 GPM. Designed for the professional with heavy-duty cast iron construction, Noryl® internals and factory wired pressure switch for years of extended service. Available in 1/2 HP model.
Applications:
Ideal for homes, farms and cottages.
SPECIFICATIONS Pump Case – Cast iron
Diffuser – Reinforced Polypropylene
Seal Plate – Cast iron
Impeller – Noryl
Mechanical Shaft Seal, Type 6 – Buna-N, Carbon, Ceramic, 18-8 stainless steel
Nozzle – Acetal
Venturi Tube – Acetal
1⁄4” NPT Pipe Plug – Zinc plated steel
Mounting Base – Steel
FEATURES Precision Molded Noryl® Impeller with 300 grade Stainless Insert – High performance and efficiency with high strength for longevity.
Precision Molded Reinforced Polypropylene Diffuser, Nozzle and Venturi – High performance and efficiency with superior abrasion resistance.
Cast Iron Pump Case with 1-1/4” Suction and 1” Discharge Ports,Two 1/4” Auxiliary Pressure Ports and Cleanout Plug – Facilitates plumbing of accessories and easy access to nozzle for cleanout.
Rugged Cast Iron Seal Plate – Positive alignment between pump case and motor.
Factory Installed Pressure Switch with Fixed 20 lb. Differential and 1/4” FNPT Port – Industry standard switch is easily field replaceable.
Every Pump Unit is Factory Tested – Peace of mind for you and your customers.
