Product Description
Rev-a-shelf Natural Maple Charging Drawer for Full Access 18" w/ BLUMOTION Soft-Close 4WCDB-18HFLSC-1
Charge all your electronics together in one location with Rev-A-Shelf's 4WCDBH Series Charging Drawer System.
Series Name 4WCDB-18HFLSC-1
Short Description Natural Maple Charging Drawer for Full Access 18" w/ BLUMOTION Soft-Close
Primary Color Natural Maple
Primary Material Wood
Frameless Min. Cab. Opening Width (inches) 16 1/2"
Frameless Min. Cab. Opening Depth (inches) 22 3/4"
Frameless Min. Cab. Opening Height (inches) 4 1/2"
Inset Min. Cab. Opening Width (inches) 16 1/2"
Inset Min. Cab. Opening Depth (inches) 23 1/4"
Inset Min. Cab. Opening Height (inches) 4 1/2"
Width (min to max): 16 1/2"
Depth (min to max): 22 7/16"
Height (min to max): 4 5/16"
Door Mountable Required, Included
Installation Type Drawer Replacement
Mount Type Cabinet door, rear and side walls
Drawer Compartments (1) compartment
Primary Finish Semi-gloss
TSCA Title VI Yes
Order Increment 1
SPECIAL FEATURES:
Designed for 18" base cabinet
drawers
Drawer front not included
5/8" drawer side material, natural maple construction with semi-gloss finish
Full-extension, TANDEM, 90 lb. rated, concealed slides with BLUMOTION soft-close
(2) charging configurations:
- (2) 120V plugs and (2) 2.1 amp USB ports
- (4) 2.1 amp USB-A ports w/(1) USB-C adapter
Tamper resistant outlets
Max Current: AC: 12 amps @ 120VAC; USB 2.1 amp & 5 VDC
UL recognized to UL962/CSA-C22.2 No. 0-10
Power cord with NEMA 5 - 15
plug
Integrated cord guide to ensure safe operation
Door mount brackets
Shock absorbent mat, black
Overall safety of this product is determined by its end use
TSCA Title VI compliant
