Product Description
Oliver 12” Parallelogram Jointer with HCX Helical Cutterhead 5HP 1Ph 4265C.051T
NO SALES TAX EVER!
Experience unwavering precision and unmatched performance with the Oliver Machinery 12" Parallelogram Jointer with HCX Helical Cutterhead. This industrial-grade powerhouse caters to professional woodworkers and demanding enthusiasts, delivering exceptional flatness, effortless jointing, and robust durability for years of reliable service.
Extra-long precision ground tables provide a stable work surface. Parallelogram design provides smooth accurate cuts. Massive cast iron frame offers stable table support. Helical cutter head includes premium carbide inserts. 4-sided cutting inserts are indexed and easy to replace. Wixey DRO shows table infeed table movement for precision cuts. Pre-drilled bracket for easy (optional) powerfeed mounting. Foot activated emergency power shutoff. Lever controlled outfeed table allows easy adjustment. Rack & Pinion style cast-iron fence features positive stops at 45° and 90°. Easy to read depth of cut gauge. Powerful TEFC motor available in single phase. Poly V-belt drive efficiently delivers power to the cutter head.
Model Number 4265C
Stock Number 4265C.051T (5HP, 1Ph)
Infeed Table Travel 3/4"
Cutterhead Speed 5,500 (RPM)
Number of Knives (helical) 56 Inserts
Maximum Depth of Cut 1/8"
Rabbeting Capacity 3/4"
Dust Port Diameter 6"
Table Dimensions 88”L x 12”W
Table Height 34-3/4”
Fence Dimensions 47”L x 6”W
Fence Tilts 45°
Positive Stops 90° and 45
Motor 5HP 3Ph 230/460V
Overall Dimension 88”L x 29”W x 55”H
Net Weight 814 lbs. / Gross Weight 980 lbs.
