Product Description
Freud Solid Wood Surfacing & Rabbeting Bit TM1470
Surface finishing and rabbeting with CNC Routers
ECHNICAL SPECIFICATIONS
NUMBER OF CUTTERS 4
OVERALL DIA. (D) 1-1/2"
OVERALL LENGTH (H) 2-1/4"
SHANK DIA. (A) 1/2"
CARBIDE HEIGHT (H) 1/2"
MAX RPM 16000
Specifically designed for CNC machines to deliver long cutting life, maximum durability and high quality finish
Enhanced TiCo™ Super Density Carbide with chromium designed and manufactured by Freud for 2x cutting life
Advanced cutting geometry for superior chip evacuation and finish quality
PRODUCTOVERVIEW
Freud's Solid Wood Surfacing & Rabbeting Bit is the ideal CNC tool for routing a fine, flat surface on solid hardwood or softwood, or for routing precise rabbets along the edge of solid wood panels. The replaceable solid carbide inserts can be rotated so all 4 edges are used, providing extremely long life, even in abrasive materials. Cutting diameter: 1-1/2", 1/2" shank.
Specifically designed for CNC machines to deliver long cutting life, maximum durability and high quality finish
Enhanced TiCo™ Super Density Carbide with chromium designed and manufactured by Freud for 2x cutting life
Advanced cutting geometry for superior chip evacuation and finish quality
Ideal For: CNC use for surfacing solid wood and rabbeting edges.
REPLACEMENT PARTS:
#TM1465-RPLKS - 4pc Replacement Insert Knife Set
#VT05MAA9 - 1pc Countersink Screw
#VT71MAA9 - 1pc Insert Locking Screw
