Product Description
DEWALT 20V Max Rotary Hammer, Sds Plus, L-Shape, On-Board Dust Extractor, 1-1/8-Inch DCH263R2DH
Bit lengths up to 1-inch in overall length
Bright LED to help illuminate dark work areas.
Constant speed underload for fast speed of application
Cordless hammer drill has 3. Joules of impact energy for fast drilling in concrete.
DEWALT 2V hammer drill has a wide optimal drilling range between 1/4 inch and 3/4 inch
Factory-set clutch of DEWALT 2V brushless hammer drill reduces sudden, high-torque reactions if bit jams.
Optimized ergonomic design provides an exceptional drilling and chipping experience in overhead, horizontal and downward orientations.
Quick release for easy tool assembly and disassembly
SHOCKS-Active Vibration Control system reduces vibration felt at the handles, compared to hammers without this feature.
Three replaceable optimized dust nozzle heads are tuned for up to 1-inch diameter bits, all stop bits up to 1.5-inch shoulder and small diameter bits up to 1/2 inch
UPC Code: 885911625203
The DCH263R2DH 20V MAX XR Brushless 1-1/8-inch SDS Plus D-Handle Rotary Hammer Kit with onboard dust extraction is a light weight, low vibration, high-performance drill designed for the demands of today's contractor. The durable three mode German engineered mechanism delivers 3.0 joules of impact energy that delivers fast speed of application that professionals require. This allows the DCH263R2 Hammer to perform quickly in chipping applications and have a wide optimal drilling range between 1/4-inch and 3/4inch The DCH263R2DH kit features the 6.0 Ah DCB206 battery pack for extreme runtime. SHOCKS-Active Vibration Control system reduces vibration felt at the handles, compared to hammers without this feature. With its hard-hitting mechanism, fast drilling speed, long run time and balanced design, this DEWALT cordless hammer drill is ideally suited for all day use, even with large diameter hole drilling in the hardest concrete. The DCH263R2DH features the OSHA Table 1 Compliant DWH205DH. This dust extraction system features a powerful built in motor for increased suction and high-performance drilling. The two second power-off delay ensures that dust extraction continues after drill is switched off. The DWH205DH features three nozzle heads for maximum dust collection during the application. The included nozzles are tuned for up to 1-inch diameter bits, all stop bits up to 1.5-inch shoulder and small diameter up to 1/2-inch This dust extractor allows for bit lengths up to 10-inch in overall length for drilling applications. This allows users to install a wide range of anchors including pinch nails, rod hanging systems like dropins, large diameter sleeve, stud/wedge, and screw anchors. This unit includes an OSHA 1926.1153-compliant Dust Box Assembly. Equipped with a filter cleaning mechanism and a HEPA filter, it removes 99.97% of airborne particles 0.3 microns or greater.
Specification
Country of Origin
China
Cordless/Corded
Cordless
Battery Amp Hours (Ah)
5 Ah
Charger Included
Yes
Voltage
20 V
Battery Included
Yes
Battery Type
20V MAX* Lithium Ion
Application
DRILLING
Packaging
Item Length
25.6 IN
Item Height
6.5 IN
Item Width
19.9 IN
Item Weight
24.1 LB
Master Pack Height (Inches)
13.5 IN
Master Pack Length (Inches)
26.0 IN
Master Pack Quantity
2
Master Pack Weight (lbs)
52.0 LB
Master Pack Width (Inches)
20.5 IN
Pallet Height (Inches)
47.1 IN
Pallet Length (Inches)
48.0 IN
Pallet Quantity
12
Pallet Weight (Pounds)
312.2 LB
Pallet Width (Inches)
40.0 IN
Includes
(1) Dch263 Rotary Hammer
(1) Low Vibration Side Handle
(1) Depth Rod
(2) Dcb206 Batteries
(1) High Speed Charger
