Product Description
Aventos HF Top 22F25 AND 22F28 Screw On and System Screw Mount Power Factors of 238-1188 and 880-1698
AVENTOS HF bi-fold lift system, lift mechanism (Set), PF=2600-17250 (with 2 pieces), suitable for SERVO-DRIVE
Bi-fold door
Height range: 480 (18-7/8") to 1219 (48")
Cabinet widths up to 1828 (72")
– Ideal for taller wall cabinets with bi-fold doors
– Cabinet height 480 (18-7/8") to 1219 (48")
– Cabinet width up to 1828 (72")
– Inside depth of at least 264 (10-3/8")
– Integrated BLUMOTION for soft and effortless closing
– Light operating forces
– Variable stop
– Integrated opening angle stop
– Fixed position of the lift mechanism and mounting
plate for lever
– Symmetrical levers
– Tool-free assembly
– Two lift mechanism fixing methods
– 3-dimensional adjustment of both doors
– Center hinge with finger safety feature
Note
Power factor = cabinet height* [inch] x combined door weight including handle weight [lb]
*Calculate with theoretical cabinet height (TKH) for asymmetrical doors
For asymmetrical doors: theoretical cabinet height (TKH) = door height top (FHo) [inch] x 2 + gaps
The larger door must be at the top for asymmetrical doors.
We recommend the more powerful lift mechanism for applications in overlapping ranges. A trial application is recommended when you are in a borderline area of the
individual lift mechanism's power factor range.
The power factor can be increased by 50% when using a third lift mechanism.
We recommend a third lift mechanism for wide cabinets. This will prevent the door from sagging when open.
Lift mechanism set Fixing with wood screws and positioning system
Set includes:
‒ Symmetrical lift mechanism with positioning system (qty 2)
‒ Wood screws Ø4 x 35 (qty 8)
Power factor 238–1188 is Part no. 22F2500 OR Power factor 880–1698 is Part no. 22F2800
Lift mechanism set Fixing with pre-attached system screws
Set includes: Symmetrical lift mechanism with pre-attached system screws (qty 2)
Power factor 238–1188 is Part no. 22F2510 OR Power factor 880–1698 is Part no. 22F2810
