Product Description
General Rugged Recording Video Inspection Camera/Borescope with 7 Inch Screen and High-Performance Probe DCS2000
The #DCS2000 Rugged Recording Video Inspection Camera/Borescope with 7 Inch Screen and High-Performance Probe is General’s best-of-breed offering. It's ideal for professional close-up examinations of hard-to-see and hard-to-reach areas.
7 in. (178mm) diagonal LCD with HD (800 x 480 pixel) resolution
1m (39 in.) long x 5.5mm (0.22 in.) diameter flexible-obedient P16181HP high-perfornance probe; probe is available in 2m and 3m lengths
Camera lighting by six LEDs—four facing forward and two at an angle—provides glare-free viewing in any environment
Light boost, anti-reflection and 90 frame rotation buttons on probe handle maximize visibility of any inspection target
Probe and stainless steel camera head are IP67 water, oil and dust-proof. Console is IP57 water, oil and dust-proof, and drop-proof from height of 1m (39 in.).
Records VGA resolution video clips (with voice annotation) and still images using familiar menu-driven user interface. Saved video and photo files incorporate real-time brightness and zoom adjustments made prior to recording or "on the fly" to optimize ta
Easy-to-navigate album-style (3 x 3 grid) display of all stored media files
Different areas of interest on saved photos can be selected for extreme close-up viewing
Field of view can be enlarged up to 5X, mirrored horizontally, or rotated 90°, 180° or 270°. Features can be applied alone or together to make targets easier to inspect and serial numbers easier to read.
4GB SD memory card
Analog video out/headphone jack
USB cable for uploading media on the SD card to a PC without ejecting the card
110° mirrored probe viewing tip
Console is compatible with longer and articulating VGA resolution probes from General
Adjustable Auto Power Off triggering time
Choice of 27 menu languages
Custom airtight hard plastic carrying case
Hand strap and tripod mount
CONSOLE:
Display: 7 in. (178mm) diagonal TFT color LCD
Display resolution: 800 x 480 pixels
Ingress protection: To water, oil & dust per IP55 standard
Impact resistance: Drop from height of 1m (39 in.)
Recording resolution: 640 x 480 pixels (VGA)
Video zoom options: 1.5X 2X, 5X
Frame rotation options: 90°, 180°, 270°
Interfaces: USB 2.0 and A/V jacks
Analog video out formats: NTSC and PAL
Recording nedium: Standard-size SD card of up to 32GB capacity (4GB card included)
Capacity of included 4GB SD card: Three hours of VGA resolution video consuming an average of 26 Mbytes/minute
Operating temperature: 14° to 140°F (-10° to 60°C)
Weight: 2.6 lb. (1.18kg)
Power source: Rechargeable Lithium-polymer battery or #AC3 Adaptor/Charger (included)
P16181HP PROBE:
Length/type/diameter: 1m (39in.)/flexible-obedient/5.5mm (0.22 in.)
Diameter of camera head with thread protector installed: 6mm (0.23 in.)
Probe/camera head ingress protection: From water/oil/dust per IP67 standard
Camera resolution: 640 x 480 pixels (VGA)
Camera depth of field: 0.25 to 12 in. (6.4 to 300mm)
Camera field of view: 60°
Camera lighting: Six LEDs—four forward-facing + two at an angle
Includes
Console
#P16181HP high-performance probe
110° mirrored probe viewing tip
4GB SD memory card
USB cable
#AC3 AC Adaptor/Charger
Airtight hard plastic carrying case
Hand strap
1-year limited warranty
Dimensions
9.45 x 6.06 x 1.85 in. (240 x 154 x 47mm)
